Power Flame CX Burner
Power Flame CX Burner
Product logo

Type CX - Small Diameter Tube Gas Burner

The Power Flame Type CX Small Diameter Tube Gas Burner is designed to fire directly into small diameter (1 1/2″ to 6″) immersion tube heat exchangers. It is used to heat water and similar aqueous solutions in a wide variety of commercial and industrial process applications. The Power Flame CX burners feature an innovative technology that requires no combustion chamber and minimal intrusion into the heat transfer working area. CX burners operate directly into a small diameter immersion tube heat exchanger, which is submerged in the liquid to be heated. The immersion tube varies in size from 1.5″ to 6″ nominal diameter. – High efficiency (in excess of 80%) heat transfer – Multiple burner installations can be designed to operate with a common flue – Smaller diameter and shorter length of heat exchanger permit compact vessel design, reducing installation and heat exchanger construction costs – Lower maintenance costs. No moving parts on burner housing – Rugged construction with no exposed operating parts or electrical connections allows CX burners to operate in a wide variety of process environments The CX Series system is a fully integrated combustion package. Power Flame provides single responsibility for control system design, burner and fan selection, as well as the optimum heat exchanger configuration. The computer-generated CxCALCTM produces a timely response to complex design parameters.

Power Flame Type CX Gas Burner Datasheet
Power Flame Type CX Gas Burner Manual
